| | Number of channels | 1598 |
| BDS |
B1I,B2I,B3I, B1I,B3I,B1C,B2a,B2b
|
| GPS | L1C/A,L2P,L2C,L5,L1C* |
| GLONASS | G1,G2,G3* |
| GALILEO | E1,E5b,E5a,E5 AltBoc*,E6c* |
| QZSS | L1 ,L2C, L5/ IRNSS:L5*/ SBAS:L1C/A,L5* |
| Positioning output rate | 1Hz~20Hz |
| Differential support | CMR,RTCM2.X,RTCM3.0,RTCM3.2 |
| Static format support | GNS, Rinex dual format static data |
| RTK positioning accuracy | Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm
(D is the distance between the measured points) |
| Static positioning accuracy | Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points)
Elevation: ±(5+0.5×10¯6D) mm
(D is the distance between the measured points) |
| DGPS positioning accuracy | Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm |
| Initialization time | <10 seconds |
| Initialization reliability | ＞99.99% |
| IMU tilt compensation | Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30°
IMU tilt angle:0°~60° |
| | NFC wireless communication | Adopting NFC wireless communication technology, the manual can automatically pair with the host by touching it (the manual
alsoneeds to be equipped with an NFC wireless communication module) |
| WiFi | 802.11b/g access point and client mode, can provide WiFi hotspot service |
| Bluetooth | BLEBluetooth 4.0 standard, support for android, ios cellphone connection |
| Wireless modem | Built-in radio, typically work range can be 8KM Radio repeater |
| I/O port | 5PIN LEMO external power port + RS232, 1 radio antenna interface, Type C , Micro SIM card |
| frequency band: | 410-470MHz |
| Protocol | SOUTH,Farlink,TrimTalk,ZHD, HUACE |
| | Buttons | Power key |
| Indicators | Three indicator lights+Battery display light (at the bottom of the instrument): data light, Bluetooth light, power light (button
position) |
Electrical physical properties | battery | Internal Li-on, 6800mAh, 7.4V |
| Power Supply | 9-25V DC, overvoltage protection |
| size | 135mm(Diameter)x84.75mm(Height) |
| weight | 0.89kg (battery included) |
| material | Magnesium aluminum alloy shell |
Environmental characteristics | Dust and water release | IP68 standard, protected from long time immersion to depth of 1m |
| Storag | -55°C~+85°C |
| Operating | -45℃~75℃ |
| | | Built in temperature sensor, using intelligent variable frequency temperature control technology to monitor and adjust the
hosttemperature in real-time |
| | model | H6 |
| operating system | Linux |
| CPU | 2.0 GHz eight-core processor |
| Memory | 3GB RAM |
| Storage | 32GB |
| | Network | TDD/FDD-LTE 4G |
| WiFi | 802.11b/g access point and client mode, can provide WiFi hotspot service |
| Bluetooth | BT4.2(BR/EDR+BLE) |
| NFC | Support NFC IGRS |
| USB | Mini USB, supports OTG |
| | Battery | 7.4V, 3400mAh |
| Battery life | 12 hours |
| Charging | < 4 hrs for full charge |
| | size | 131mm*80mm |
| Weight | 800g |
| Operating temperature | -35℃ ~ +80℃ |
| Voice | IVoice intelligent voice technology, intelligent status reporting, voice operation prompts; Chinese, English, Korean, Russian,
Portuguese, Spanish and Turkish are supported by default; Support for voice customization |
Data storage/transmission | | Built-in 4GB solid-state storage, rich sampling intervals, and support for raw observation data collection up to 20Hz |
| data transmission | Supports data transmission such as USB, FTP download, HTTP, etc |
| | Static data formats: various formats such as Southern STH, Rinex2.01, and Rinex3.02 Differential data format: RTCM3.0, RTCM3.2
input and output GPS output data format: NMEA 0183, PJK plane coordinates, binary code Network mode support: VRS, FKP, MAC,
support for NTRIP protocol |
